[HAILI Technology] Polyethylene (PE) knowledge quiz, can you answer correctly?

1、What is a pipe jacking?

A: It is a non-excavation construction method, which is a pipeline burial technology that does not excavate or excavate less. This is very important for cities with heavy traffic, dense population, numerous ground buildings and complex underground pipelines.

2、What is the reduction factor of the working temperature on the working pressure of the pipeline? What is the pressure reduction factor for the temperature of the polyethylene piping system?

Answer: The pipeline is continuously used at a working temperature above 20 °C, and the working pressure is proportional to the working pressure at 20 °C.

When the polyethylene piping system is continuously used at a temperature above 20 °C, the maximum working pressure (MOP) shall be calculated as follows: MOP = PN × f1 (wherein, f1--- reduction factor, The data is checked in the table below.)

50-year life expectancy, pressure reduction factor below 40 °C

 3、What is the ring stiffness SN? What do SN4 and SN8 stand for?

A: The numerical value of ring stiffness is widely used in the world to indicate the resistance to external pressure load of plastic buried drain pipes. If the ring stiffness of the pipe is too small, the pipe may be excessively deformed or fractured and unstable. On the other hand, if the ring stiffness is chosen too high, it is inevitable to use an excessively large section moment of inertia, which will result in too much material and too high cost.

SN4 and SN8 represent the difference in ring stiffness, SN4 represents ring stiffness ≥ 4KN/m2, and SN8 represents ring stiffness ≥ 8KN/m2.

4、What are the uses of PE pipes?

A: PE pipe can be widely used in urban water supply systems, food, chemical industry transportation systems, mineral sands, mud conveying systems, landscaping pipe networks, replacement cement pipes, cast iron pipes and steel pipes.
